Cathodic Protection Systems (CCP): Complete Corrosion Defense Solutions

We provide comprehensive Cathodic Protection (CP) Systems, including both Sacrificial and Impressed Current (ICCP) solutions, engineered to safeguard critical metal infrastructure against corrosion in diverse and challenging environments.

Request a Quote

The Necessity of Cathodic Protection Systems

Corrosion is a relentless threat to metal assets, leading to structural failure, environmental hazards, and significant financial loss. A Cathodic Protection (CP) System is a proven, cost-effective method to mitigate this threat by applying an electrochemical technique that stops the corrosion process, extending the lifespan of pipelines, marine structures, storage tanks, and more.

Two Primary Types of CP Systems

System Type	Mechanism	Best Suited For	Key Component
Sacrificial (Galvanic) CP	Uses a more active metal (anode) that corrodes preferentially.	Smaller, well-coated structures; low-resistivity environments (seawater).	Zinc, Aluminum, or Magnesium Anodes.
Impressed Current CP (ICCP)	Uses an external DC power source to drive current from an inert anode.	Large, complex structures; high-resistivity environments (soil, concrete).	MMO, HSCI Anodes, and Rectifiers.

Key Components of Our CP Systems

A complete CP system involves several critical components working in harmony to deliver effective protection.

1. Anodes (The Current Source)

Sacrificial Anodes: Zinc, Aluminum, and Magnesium in various forms (hull, bracelet, rod).
ICCP Anodes: Mixed Metal Oxide (MMO) in tubular, ribbon, or disc configurations; High Silicon Cast Iron (HSCI).

2. Power and Control (For ICCP Systems)

Transformer Rectifier Units (TRU): Converts AC power to the necessary DC current, with precise control and monitoring capabilities.
Junction Boxes and Cables: Ensures safe and reliable distribution of the protective current.

3. Monitoring and Assessment

Reference Electrodes: Copper/Copper Sulfate (Cu/CuSO₄) or Silver/Silver Chloride (Ag/AgCl) electrodes to accurately measure the structure's potential.
Test Stations: Access points for periodic monitoring and system assessment.

Why Partner with Us for Your CP System Needs?

Integrated Solutions

We design, supply, and support both Sacrificial and ICCP systems, offering the optimal solution tailored to your specific asset and environment.

Expert Engineering

Our team provides comprehensive services, including corrosion investigation, system design, installation support, and effectiveness testing.

High-Quality Components

All system components, especially our advanced MMO and sacrificial anodes, are manufactured to strict international standards for maximum durability and performance.

Long-Term Cost Savings

By preventing corrosion, our CP systems significantly extend asset life, reducing maintenance costs and avoiding costly replacements and downtime.

Broad Application Areas of CP Systems

Oil & Gas Infrastructure: Protecting buried pipelines, well casings, and storage tank bottoms.
Marine & Offshore: Ship hulls, offshore platforms, subsea pipelines, and port facilities.
Water & Wastewater: Internal protection of water storage tanks, clarifiers, and heat exchangers.
Civil Infrastructure: Corrosion prevention for steel reinforcement in concrete bridges and tunnels.

Secure Your Assets with a Custom Cathodic Protection System

Contact our expert engineers today for a comprehensive corrosion assessment, system design consultation, and a detailed quote.
